Dewalt DWE7480 vs DW745 Table Saw : Which is Better?

In Brief: Dewalt DWE7480 vs DW745

Dewalt DWE7480 and DW745 are two impressive Table Saws from the same manufacturer. Both products have impressive working capacities with some differences in their specifications. DWE7480 has a faster blade speed (4800RPM) compared to DW745 (3800RPM). Dewalt DW745 has a lower weight compared to dwe7480. The rip capacities of Dewalt DWE7480 and DW745 are 4800RPM and 3850RPM respectively.

Dewalt is a manufacturer that has made a significant impact in the tool manufacturing industry.

The manufacturer has so many power tools that offer effective woodworking solutions in various categories.

Dewalt DWE7480 and DW745 are two core offerings from this manufacturer in the table saw category.

In this relative evaluation, we would consider their difference, unique specifications, and individual applications.

Dewalt DWE7480 vs DW745 at a Glance

Making comparative evaluation is an effective strategy in making the best choice on the power tool to suit your woodworking needs.

Ideal for45lbs48lbs
Motor Current15amp15amp
Blade Length10”10”
Arbor Size5/8”5/8”
Power sourceElectric PoweredElectric Powered
No-load Speed3850RPM4800RPM
Rip Capacity to the right20”24”
Rip Capacity to the left12''12''
Size of Dust Port2-1/2”2-1/2”
Depth of Cut at 452-1/4”2-1/2”
Depth of Cut at 903-1/8”3-1/8”
PriceRelatively affordableModerately priced
Warranty3-year limited warranty3-year limited warranty
Unique Features - Lightweight and compact
- Rack and Pinion rail system
- Onboard storage system
- Adjustable rear feet
- Metal roll cage
- Site-Pro guarding components.

Dewalt DWE7480 vs DW745 : Weight

Most purchasers of power tools, particularly homeowners, hobbyists, and multiple jobsite contractors usually prefer lightweight products that they can easily carry around.

Both Dewalt DWE7480 and DW745 are lightweight, but the weight of DWE7480 is slightly higher than DW745.

Weight of DWE7480

Dewalt DWE7480 is a lightweight table saw with a simple and compact design. This power tool weighs 48lbs.

Although this weight is slightly higher than DW745, it doesn’t change the fact that this table saw is one of the lightest models in its category.

Weight of DW745

The consideration of weight is one of the key reasons why Dewalt DWE745 is a leading choice for jobsite contractors.

This portable and compact table saw weighs 45lbs thus, making it easy to handle and transport.

Dewalt DWE7480 vs DW745 : Blade Speed

The blade speed of a table saw is a key determinant of its cutting capacity and overall performance. The blade speed capacity of Dewalt DWE7480 is significantly higher than that of DW745.

Blade Speed of DWE7480

Dewalt DWE7480 has one of the most impressive blade speeds compared to other products in this category. Its motor propels its blade to make a no-load speed of 4800RPM.

At this speed, this power tool is capable of making fast, smooth, and neat cuts on several types of materials, including hardwoods.

Blade Speed of DW745

Dewalt DW745 also has impressive cutting blade speed.

This power tool can make a no-load speed of 3850RPM to ensure fast and impressive cuts on varieties of materials.

Although lower than DWE7480, its cutting capacity at this speed makes it a good choice for users.

Dewalt DWE7480 vs DW745 : Cutting Capacity

Like their blade speeds, Dewalt DWE7480 and DW745 have remarkable cutting capacities. Both power tools have similar cutting capacities but Dewalt DWE7480 has a more extensive rip capacity to the right of its blade compared to DW745.

Cutting Capacity of DWE7480

Overall, Dewalt DWE7480 has impressive cutting capacity. This table saw has a rip capacity of 24” to the right of blade and 12” to the left. Likewise, this table saw is capable of making a 2-1/2” deep cut at 45⁰ and 3-1/8” at 90⁰.

Cutting Capacity of DW745

Dewalt DW745 also features impressive cutting capacities. This table saw can make a 2-1/4” deep cut at 45⁰ and 3-1/8” at 90⁰. Likewise, it has a rip capacity of 20” to the right of blade and 12” to the left.

Dewalt DWE7480 vs DW745 : Motor Setup

The motor setup of a table saw is one of the crucial factors that influence its operation. The motor setup of Dewalt DWE7480 and DW745 are similar, with the major difference coming from their power rating.

Motor Setup of DWE7480

Dewalt DWE7480 has an impressive motor setup that ensures its smooth operation and delivers a no-load speed of 4800RPM. This model features a 15amp, 1850-watt motor that uses a 120V power.

Motor setup of DW745

Dewalt DW745 has a similar motor setup with DWE7480. This model includes a 15amp, 120V, and 1400-watt motor that delivers an impressive no-load speed of 3850RPM.

Dewalt DWE7480 vs DW745 : Warranty

Dewalt DWE7480 and DW745 have the same warranty offer primarily because they belong to the same product category from the same manufacturer

. The warranty on both products includes a 90-days money-back guarantee.

Warranty of DWE7480

Dewalt DWE7480 like most other table saws from this manufacturer is covered by a 3-year limited warranty on any factory defect in craft and materials.

The warranty also features a 1-year service and repair support in various service centers authorized by the manufacturer.

Warranty of DW745

This model features a 3-year limited warranty of any factory defect in workmanship and materials of the product.

It also includes 1-year free service and repair support in manufacturer certified service centers.

Standout Features

Unique Features of DW745

 Telescoping fence System: This model features a telescoping system that guides its cutting operation. This fence system is also retractable to give a small and portable package.

 Onboard Storage System: Dewalt DW745 features a built-in storage system that grants quick access to tools and other parts of the table saw that are in prospective use. It primarily offers quick access to the components like the Site-Pro guarding components and push sticks when not in use.

Rack and Pinion Rails: This integrated feature of Dewalt DW745 allows easy, fast, and smooth adjustments for easy maneuverability. This feature enhances the secure handling of the product and precise, quiet, and accurate cuts.


Unique features of DWE7480

 Adjustable rear feet: This model features adjustable rear feet that provide sturdiness, stability, and rigidity for the product. Likewise, it allows the table saw to retain balance on uneven surfaces.

Metal roll cage: The metal roll cage of Dewalt DWE7480 improves the durability of the product compared to other products with plastic base.

Table Coating: Dewalt DWE7480 has a suitable table coating that reduces surface friction and enhances smooth and accurate cuts.


Which Table Saw Is Better ? Dewalt DWE7480 or DW745 ?

Use DWE7480 if :

Dewalt DWE7480 is a portable and lightweight table saw with a compact design.

You can consider this product if you are working within a moderate budget.

This product is ideal for professionals, homeowners, and jobsite contractors that need a professional table saw that offers quick and efficient cuts on varieties of materials.


Use DW745 if :

You should use Dewalt DW745 if you desire the woodworking service of an affordable, lightweight, compact, portable, and easy-to-use table saw.

This table saw offers considerable high value for money for users with a medium and low budget.

It is ideal for amateurs and beginners because of its easy-to-use features that enhance smooth and accurate cuts.
